In the past, it required a team of camera operators to control multiple cameras simultaneously. However, with advancements in technology, it is now possible to control multiple robotic (PTZ) cameras with just one click. This capability is particularly beneficial when you need to execute "scene changes," where you want one or more PTZ cameras to move to a new location simultaneously.

1. What are the benefits of using KBC10  controller to control  FEELWORLD 4K12X PTZ camera？

1. Simultaneous Control:

A console allows you to control multiple PTZ cameras simultaneously from a centralized location. With multiple cameras, it can become challenging to manually adjust each camera's position using individual remote controls. The console provides a unified interface that enables efficient and synchronized control over all cameras, allowing you to manage their movements seamlessly.

2. Precise Positioning:

PTZ cameras offer pan, tilt, and zoom functionalities, and a console provides more precise control over these movements compared to a remote control. With a console, you can make fine adjustments to the camera's position, ensuring accurate framing and capturing the desired visual elements. This level of precision is particularly important in professional settings where exact ptz camera positioning matters.

2. How to you operate your KBC 10 PTZ camera controller?

IP settings:

You can press the IP button and enter the IP address of the first camera.Button part enter “1 2 5 9” and press enter to confirm.camera number here enter "1" and press enter to,confirm your controller has successfully identified the PTZcamera.When you see success on the LCD screen,you can control your PTZcamera by using the joystick.

Joystick control:

Repeat the above steps and you can add camera 2 and camera 3 to your KBC 10 controller. You can hit "Camera 1" and control it. when you see the PTZ camera,you can scroll up, scroll down, move left or right, twist right to zoom in, and left to zoom out .

Button description:

Here is another way for you to control the zoom, go to the panel and press the zoom button on the panel. There is an autofocus button and an auto iris button, you use the "AUTO FOCUS" and "AE AUTO" buttons to put the camera in autofocus mode or auto iris mode. If you want to adjust it manually, you can go to the "FOCUS" or "IRIS" knob in the top right corner. In the right-hand corner, there is a knob for red adjustment and a knob for blue adjustment,you can also adjust PTZ speed by scrolling a knob here.



Conclusion

As video production software has allowed producers to add camera control to their workflow, more has become possible. Controlling multiple PTZ cameras at once during a production can make life easier for operators.
